| Polar Pattern |
Cardoid / Omni-directional / Figure-of-eight |
| Freq. Response, Hz |
20-20000 |
| Output sensitivity, mV/Pa |
13 |
| Power |
Power Block supplied |
| Nominal Output Impedance |
200ohm |
| Minimum load impedance |
1 k ohm |
| Maximum SPL @ 1kHz |
> 135dB |
| Maximum Output Voltage |
1.2V |
| Current Consumption |
8mA |
| Temp. Range |
-35degrees C to +45 degrees C |
| Relative Humidity |
85% (+25 degrees C) |
| |
|
|
